ShanDong HangKang Medical Equipment Co.,Ltd.
6 Years
| Ask Lasest Price | |
| Brand Name : | HangKang |
| Model Number : | LK-YAN7200A |
| Certification : | CE/FDA |
| Price : | $8,749.00 - $20,000.00 |
| Payment Terms : | T/T, T/T |
| Supply Ability : | 1000 Unit/Units per Week |
| Delivery Time : | Within 7 days after getting payment |
Gas requirement: Medical oxygen and nitrous oxide with a pressure ranging from 280~600kpa
safety valve <12.5 kPa
Respiratory Rate 1~99 bpm
gas concentration output 21% ~ 100% adjustable
Maximum Minute ventilation ≥18L / min, permissible deviation: ±20 %
Breathing Mode A/C, SIPPV,IPPV,SIMV,PSIMV,CPAP,PCV, PEEP,SIGN,VCV, SPONT, MANUAL
Ventilator compliance ≤30 Ml/kPa
PEEP: 0~1.0KPa
Ptr: ,-1.0~1.0 kPa
IMV frequency: 1 ~ 12 times/min, permissible deviation: ±15%.
I/E Ratio: 4:1~1:4
Tidal Volume range 0~2000ml
Inspiratory Plateau: 0~1s
Maximum Safety Pressure ≤ 6.0kPa
Sigh: one deep breath per 80 controlled respirations, the inspiration time is 1.5 times of the setting point and the permissible error is -10% or 15%.
Pressure limit range: 1.0~ 6.0kPa
Airway pressure alarm: Audible and visual and with yellow and red color indicating upper alarm: 0.9 kPa ~ 5.4 kPa
lower: 0.5kPa
Ventilation Volume alarm: ≥ 18L/ MIN
Power Supply Alarm "Ac/dc power supply are after failing to send out alarm immediately
Alarm Time: keep >120s"
The airway pressure continues to be higher than 15 hPa ±1 hPa for 15s±1s, then the machine will raise an audible alarm, the pressure will be displayed in red and the continuous high pressure red alarm wording is displayed on the screen of the anesthetic respirator.
| Ambient temperature | 10 ~ 40oC |
| Relative humidity | no higher than 80 % |
| Atmospheric pressure | 860 hPa ~ 1060 hPa |
| Power requirement | 100-120 Vac, 50/60 Hz; |
| Air source requirement | Medical oxygen and laughing gas with a rated pressure ranging from 0.3 to 0.5MPa. |
| Attention | the AC power supply used for the anesthesia machine must be well grounded. |
| Attention | the anesthesia machine used must be equipped with a carbon dioxide monitor complying with ISO 9918:1993, an oxygen monitor complying with ISO 7767:1997 and an expiratory gas volume monitor complying with 51.101.4.2 of Medical Electrical Equipment |
| Part II | Special Requirements for Safety and Basic Performance of Anesthesia System. |
|
|
